Heat Reflective Film
Xiong County Xiashi Packing Co., Ltd. is a leading supplier of Heat Reflective Films in China, operating under the brand name Jinbo. With over 40 years of experience, our proprietary manufacturing facility maintains rigorous quality control standards and ample inventory; we also offer customization services tailored to specific requirements. We invite you to contact us for inquiries.
Xiashi Packing is a reliable manufacturer and supplier of Heat Reflective Films, operating under our own brand, Jinbo. This product was developed and manufactured by our factory specifically for architectural thermal insulation and energy-efficient heat reflection; it is primarily designed for use in applications such as prefabricated housing, steel structures, roofing systems, and wall assemblies.
What is heat-reflective film?
Heat Reflective Film is a specialized architectural material manufactured by Xiashi Packing.
1. Material Composition: PET (polyester) / aluminum foil laminate, or aluminized cast PET film.
2. Four Core Functions: Heat reflectivity, weather resistance, dimensional stability, and waterproofing/vapor barrier properties.
3. Primary Applications: Integrated housing, light-gauge steel villas, prefabricated modular buildings, steel-structure industrial plants, cold storage facilities, and roofing projects—specifically for thermal insulation, heat shielding, and energy-efficient heat reflection.
Product Advantages
1. Our Heat Reflective Film features high reflectivity and delivers exceptional thermal insulation performance.
2. The product has been engineered and rigorously tested for superior weather resistance, ensuring long-term outdoor durability without degradation.
3. It combines waterproofing and vapor barrier functions into a single solution, effectively minimizing condensation issues.
Our Services
1. By choosing Xiashi Packing, you gain access to expert technical support—including tailored recommendations and customizations based on your project's specific requirements—ensuring a smooth, trouble-free implementation process.
2. Our products feature consistent, reliable quality backed by comprehensive after-sales support; should any issues arise, please feel free to contact us at any time.
3. As the original manufacturer, we provide a complete, one-stop supply solution, saving you both time and effort.
Technical Standards
|
CRITERIA |
REFERENCE |
RESULT |
|
DUTY CLASSIFICATION |
Table 1 AS/NZS 4200.1:1994 |
Light* |
|
VAPOUR PERMEABILITY |
ASTM E96 |
4.5ug/N.s |
|
VAPOUR RESISTANCE |
ASTM E96 |
0.22MN.s/g |
|
VAPOUR BARRIER CLASSIFICATION |
ASTM E96 |
Low |
|
EMITTANCE |
AS/NZS 4201.5 |
Non-reflective |
|
WATER BARRIER |
AS/NZS 4201.4 |
High |
|
ABSORBENCY |
AS/NZS 4201.6 |
Unclassified |
|
RESISTANCE TO DRY DE_LAMINATION |
AS/NZ 4201.1 |
Pass |
|
SHRINKAGE |
AS/NZ 4201.3 |
<0.5% |
|
TENSILE STRENGTH |
AS 1301.448 |
|
|
1. Machine Direction (kn/m) |
|
4.3kN/m |
|
1. Lateral Direction (kn/m) |
|
2.4kN/m |
|
EDGE TEAR RESISTANCE |
TAPPI T470 |
|
|
1. Machine Direction (N) |
|
220N |
|
1. Lateral Direction (N) |
|
126N |
|
BURST STRENGTH |
|
>200N |
|
FLAMMABILITY INDEX |
AS/NZS 1530 Part 2 |
≤5 |
|
Allowable UV exposure prior to completion of cladding |
|
4 Months |
